| Parameter | 200/500A | 300/600A | 500/1000A | 500/1250A | 800/1600A | 800/2500A | 1000/3500A |
|---|---|---|---|---|---|---|---|
| Total Volume (L) | 200/500 | 300/600 | 500/1000 | 500/1250 | 800/1600 | 800/2500 | 1000/3500 |
| Effective Volume (L) | 150/320 | 200/360 | 375/640 | 375/750 | 600/1050 | 560/1600 | 750/2240 |
| Stirrer Speed (r/min) | 475/950 | 475/950 | 475/950 | 475/950 | 370/950 | 330/660 | 330/660 |
| Motor Power (kW) | 45/7.5 | 55/7.5 | 75/15 | 75/15 | 110/18.5 | 110/22 | 132/37 |
| Heating Method | Self-friction heating / Water cooling | ||||||
| Unloading Method | Pneumatic | ||||||
| Mixing Time (min/batch) | 8–12 | 8–12 | 8–12 | 8–12 | 8–12 | 8–12 | 8–12 |
| Dimensions (L×W×H, mm) | 4580×2240×2470 | 4580×2240×2500 | 4900×5400×2700 | 5600×3000×3100 | 5170×3200×4480 | 5170×3200×4480 | 5170×3200×4480 |
| Weight (T) | 3.5 | 3.8 | 5.5 | 5.8 | 8.6 | 11 | 12 |
